EKF 645
45° X 15 mm Beveling
The Made in Germany Portable Plate Beveling Machine For 45-Degree Chamfering and 15 mm (0.590'') Width. Provided with a robust motor of 2300 Watts (20.9 Amp) which delivers 1600 - 3000 RPM with variable speed control.
EKF 645 is available in 220-240 Volt and 110-125 Volt. EKF 645 weighs just 10.2 Kg (22.48 lbs.).
The rotary disc with recirculating bearings reduces friction resistance and energy consumption. New unique tangential plate configuration, No impact jarring when operating at low speeds, Clean milled edges, even in internal and external radii, Ideal for weld seam preparation.
 Motor Output |
2300 Watts |
 Voltage |
220-240 / 110-125 Volt (50-60 Hz) |
 Speed |
Seamless Electronic speed regulation (1600 -3000 min-1) with full wave control electronics |
 Feed |
Manual |
 Chamfer Width |
15 mm |
 Angle Adjustment |
45° |
 Milling Cutter |
ZFR 645 |
 Carbide Reversible Disc (Insert) |
SHM 900 / SHM 900 E |
 Weight |
10.2 Kg |
1 Arbour milling cutter (ZFR 645) with 10 carbide insert (SHM 900)
1 Hook wrench 58/62
1 Torx screwdriver TX 15
1 Spanner SW 22
1 Carry case
1 Operating manual
Product Video of Beveling Machines
Accessories
Arbour Milling Cutter
ZFR 645
Carbide Reversible Disc (Insert)
SHM 900 & SHM 900 E
